£126.99
Asrock H610M-ITX/EDP Intel H610 LGA 1700 mini ITX
Sold by Gotraka
Select options
Default
Shipping
£4.99
Specifications
Gotraka
5,442 items
Shop performance
Better than 66% of other shops
4+ star rating
89%
Responds within 24 hours
86%
About this product
Plug TypeNo Plug
Warranty Duriation12 Months
Product description
LGA 1700, Intel H610, 2 x DDR4 DIMM, 128Mb AMI UEFI, 7.1 CH HD Audio, Gigabit LAN, 802.11 a/b/g/n/ac, Bluetooth 5.1, Mini-ITXAsrock H610M-ITX/EDP. Processor manufacturer: Intel, Processor socket: LGA 1700, Compatible processor series: Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9. Supported memory types: DDR4-SDRAM, Maximum internal memory: 64 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, SATA III, Supported storage drive types: HDD & SSD. Ethernet interface type: Gigabit Ethernet, LAN controller: Intel® I219-V, Top Wi-Fi standard: Wi-Fi 5 (802.11ac). Component for: PC, Motherboard form factor: mini ITX, Motherboard chipset family: Intel
Built in eDP Signal Connector
Supports ASRock 13.3” Side Panel kit
An eDP signal connector is built with ASRock selected motherboards and supports two functions simultaneously - power and transmission of digital display signal. The connector reserves the room for upgrading with ASRock’s exclusive 13.3” Side Panel Kit.. The ideal 13.3" Side Panel size will be perfectly matched standard form factor chassis and users can easily build a LCD display inside the PC, adding a sub-screen for monitoring PC status, or watching videos, doing streaming or working personalized tasks. This whole new concept of customization enables new possibilities for personalizing designs - doubles productivity or entertainment.
Ultra M.2 32Gb/s (PCIe Gen3 x4 & SATA3)
The PCIe Gen3 x4 Ultra M.2 interface pushes data transfer speeds up to 32Gb/s. In addition, it also supports SATA3 6Gb/s M.2 modules.
Intel® Gigabit LAN
Intel® LAN provides the best throughput performance, lower CPU utilization, enhanced stability and is able to deliver ultimate network experience to users!
Dual Band 802.11ac WiFi
No one has time for weak WiFi signals and sluggish internet! That's why this motherboard comes with a 802.11ac WiFi (2.4G / 5G WiFi) module which supports wireless networks and Bluetooth.
Dual Graphics Outputs
Complete with two types of most used connectors! Packed with a HDMI + DisplayPort combo, you have more graphics output options now.
HDMI 4k @60Hz
Supports the most recent HDMI 4K 60Hz graphics output specification. With the larger bandwidth and increased frame rate, the motion on your screen becomes more fluid and less blurry.
Full Spike Protection
Some sensitive digital components on the motherboard are vulnerable to power surges, the excessive current may cause your system to malfunction immediately. ASRock Full Spike Protection includes various technologies to prevent your motherboard’s components from being damaged by these unexpected voltage spikes.
Processor
Maximum number of SMP processors
1
Compatible processor series
Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9
Processor socket
LGA 1700
Processor manufacturer
Intel
Memory
Unbuffered memory
Yes
Maximum internal memory
64 GB
Non-ECC
Yes
ECC
Yes
Memory channels
Dual-channel
Memory slots type
DIMM
Number of memory slots
2
Supported memory types
DDR4-SDRAM
Storage controllers
Supported storage drive interfaces
M.2, SATA III
Supported storage drive types
HDD & SSD
Internal I/O
Number of chassis fan connectors
1
CPU fan connector
Yes
ATX Power connector (24-pin)
Yes
Front panel audio connector
Yes
Number of SATA III connectors
4
USB 3.2 Gen 1 (3.1 Gen 1) connectors
1
USB 2.0 connectors
1
Rear panel I/O ports
Microphone in
Yes
Line-in
Yes
DisplayPort version
1.4
DisplayPorts quantity
1
HDMI ports quantity
1
Ethernet LAN (RJ-45) ports
1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
USB 2.0 ports quantity
4
Network
Bluetooth version
5.1
Bluetooth
Yes
Wi-Fi standards
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard
Wi-Fi 5 (802.11ac)
Wi-Fi
Yes
Wake-on-LAN ready
Yes
LAN controller
Intel® I219-V
Ethernet interface type
Gigabit Ethernet
Ethernet LAN
Yes
Features
Windows operating systems supported
Windows 10 x64, Windows 11 x64
Audio output channels
7.1 channels
Audio chip
Realtek ALC897
Motherboard chipset
Intel H610
Motherboard chipset family
Intel
Motherboard form factor
mini ITX
Component for
PC
Expansion slots
Number of M.2 (M) slots
1
PCI Express x16 (Gen 4.x) slots
1
BIOS
System Management BIOS (SMBIOS) version
2.7
ACPI version
6.0
BIOS memory size
128 Mbit
BIOS type
UEFI AMI
Weight & dimensions
Depth
170 mm
Width
170 mm
Packaging content
Cables included
SATA
