£122.49

Cooler Master XG650 Platinum power supply unit 650 W 24-pin ATX ATX Black

Sold by Gotraka

Select options

Default

Shipping

£4.99

Specifications

Gotraka
5,699 items
Shop performance
Better than 66% of other shops
4+ star rating
89%
Responds within 24 hours
92%

About this product

Warranty Duration12 Months

Product description

Intel ATX 12V Ver. 2.53, 100-240V, 8-4A, 50-60Hz, 135mm, 1800 RPM, 25 dBA, 80 PLUS Platinum, 100 - 150 ms, UKCooler Master XG650 Platinum. Total power: 650 W, AC input voltage: 100 - 240 V, AC input frequency: 50/60 Hz. Motherboard power connector: 24-pin ATX, Motherboard power cable length: 65 cm, SATA power cable length: 500,620,740,860 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Platinum. Product colour: Black, Cooling type: Active, Fan diameter: 13.5 cm. Width: 150 mm, Depth: 160 mm, Height: 86 mmSilence Is PlatinumWith a focus on thermal dissipation and maximized efficiency, this platform allows Cooler Master to offer an entirely new class of high efficiency products with 100% Japanese capacitors, boasting top-shelf performance with reduced ripple noise.First In-house Design PlatformCooler Master keeps searching for uniqueness, creativity, and more. XG Platinum is the first Cooler Master in-house designed power supply, providing next-level efficiency, rigid design, and sturdy performance to fulfill all your daily computing and gaming needs.Crafted For ExcellenceThis professional grade power supply unit is built with full-bridge LLC resonant converter and DC-DC technology, made for the all users providing stability, reliability and so much more.Silence is PlatinumXG650 Platinum offers smart thermal control mode which you can do more with your system in the minimal level of noise generated by the silent fan.Fan Up, Fan DownBoth side panels on the XG Platinum are embossed with a stylish silk screen printed design. Install your PSU in either a fan up or fan down orientation while retaining 100% of the unit's aesthetic value anytime, anywhere.Build Your WayEvery facet of the XG Platinum was chosen with the goal of maximizing efficiency and thermal performance. Full modular cables were a must so that users could minimize the number of cables in their system based on their needs, reducing clutter and increasing both airflow and aesthetic quality.Warranty: 10 Years
Power
Power protection features
Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Power Good signal delay range
100 - 150 ms
Efficiency
92%
Hold time
20 ms
Max output current (+5Vsb)
3 A
Max output current (-12V)
0.3 A
Max output current (+5V)
20 A
Max output current (+12V)
54.1 A
Max output current (+3.3V)
20 A
Combined power (+5Vsb)
15 W
Combined power (-12V)
3.6 W
Combined power (+5V)
120 W
Combined power (+12V)
650 W
Combined power (+3.3V)
120 W
Power Factor Correction (PFC) type
Active
Input current
4 - 8 A
AC input frequency
50 - 60 Hz
AC input voltage
100 - 240 V
Total power
650 W
Ports & interfaces
Cabling type
Fully-Modular
PCI Express power cable length
67 cm
PCI Express power connectors (6+2 pin)
4
EPS power connector (4+4 pin)
Yes
EPS power connector (8-pin)
Yes
Peripheral (Molex) power cable length
500,620,740,860 mm
Peripheral (Molex) power connectors (4-pin)
4
SATA power cable length
500,620,740,860 mm
Number of SATA power connectors
8
Motherboard power cable length
65 cm
Motherboard power connector
24-pin ATX
Performance
Certification
TUV, cTUVus, BSMI, FCC, CCC, EAC, UKCA
Mean time between failures (MTBF)
100000 h
Noise level
25 dB
ATX version
2.53
80 PLUS certification
80 PLUS Platinum
Power supply unit (PSU) form factor
ATX
Purpose
PC
Design
Fan speed
0 - 1800 RPM
Number of fans
1 fan(s)
Fan diameter
13.5 cm
Cooling type
Active
Product colour
Black
Operational conditions
Operating temperature (T-T)
0 - 50 °C
Weight & dimensions
Height
86 mm
Depth
160 mm
Width
150 mm
Packaging data
Package height
125 mm
Package depth
300 mm
Package width
214 mm
Technical details
Sustainability compliance
Yes
Compliance certificates
CE
Sustainability certificates
ErP
Logistics data
Products per master (outer) case
4 pc(s)
Master (outer) case height
250 mm
Master (outer) case length
520 mm
Master (outer) case width
318 mm
Other features
EPS cable length
65 cm
