W1209 Digital Thermostat Temperature Control Switch sensor Module 12V -50-110°C



-Model: W1209 -Dimensions: ABT 48.5 * 40mm -Temperature Control mode: ON / OFF -Temperature Range :-50 - 110 degree centigrade -Resolution: When temperature is 0.1 degree, the resolution is -9.9~99.9, other temperature segment is 1 degree. -Control Accuracy: 0.1 degree -Hysteresis Accuracy: 0.1 degree -Refresh Rate: 0.5s

- Probe length : about 50cm -High Temperature Protection 0 - 110 degree centigrade -Supply Voltage: DC 12V -Static Current: Less than 35MA, attract current less than 65MA -Output Voltage: DC 12V -Output Power: 20A relay  -Measurement Input: NTC (10K 0.5%) Waterproof Sensor -Environmental Requirements: -10 - 60 degree centigrade; Humidity 20% - 85%

Instructions for use:

Connect the power supply and equipment, the measuring temperature is displayed,  press the "SET" button, press " + or - " to set the desired temperature (long press " + or - " to quickly increase or decrease),  press "SET" to confirm the setting and return, controller automatically performs the relay ON/OFF.  the thermostat output is 10A relay, meet a variety of high-power loads. LED Indicator: LED off indicates the relay off;, indicates the relay is closed.  Digital LED Tubes: "LL" indicates sensor open, "HH" indicates overrange, the relay will be forcibly disconnected; "---" indicates high temperature alarm  Long press the "SET" button to enter the main menu settings,  press " + or - " to switching between P0-P6, then long press "SET" or 10 seconds without keystrokes to confirm the setting and return.





Package Included:
